21
AN30183A
Ver. AEB
TYPICAL CHARACTERISTICS CURVES (Continued)
(8) Short Protection of DC-DC1
VIN = 3.7 V, DC-DC1_Vout = 1.2 V, L1 = 1 µH , CDCDCOUT1 = 4.7 µF
IOUT
VOUT
LX
