Electrical characteristics

STM32F103x4, STM32F103x6

50/90

Doc ID 15060 Rev 6

Low-speed internal (LSI) RC oscillator

Wakeup time from low-power mode

The wakeup times given in Table 26 is measured on a wakeup phase with a 8-MHz HSI RC

oscillator. The clock source used to wake up the device depends from the current operating

mode:

●

Stop or Standby mode: the clock source is the RC oscillator

●

Sleep mode: the clock source is the clock that was set before entering Sleep mode.

All timings are derived from tests performed under ambient temperature and VDD supply

voltage conditions summarized in Table 9.

Table 25.

LSI oscillator characteristics (1)

VDD = 3 V, TA = –40 to 105 °C unless otherwise specified.

Symbol

Parameter

Min

Typ

Max

Unit

fLSI

(2)

Based on characterization, not tested in production.

Frequency

kHz

tsu(LSI)

(3)

Guaranteed by design, not tested in production.

LSI oscillator startup time

µs

IDD(LSI)

(3)

LSI oscillator power consumption

0.65

1.2

µA
