B201

DF1B Seriesq2.5mm Pitch Connector for Discrete Wire Connection (Product Compliant with UL/CSA Standard)

B Applicable Tool

BPrecautions

1. Recommended Soldering Condition

Flow: 250ç for 10 seconds

Manual soldering: 300ç for 3 seconds

2. Cleaning Condition

Refer to Nylon Connector Use Hand book.

3. Connection Condition

Refer to Nylon Connector Use Hand book.

4. Cautions

sThe color phase of this product is slightly different from that of the formed product according to

the manufacturing lot and future storage conditions, but the difference doesn't affect the

performance.

5. Precation

Refer to Nylon Connector Use Hand book.
