E3G

11

Distance-setting Models

47.8

45

Two, 4.5-dia.

mounting

holes

30

12.8

14

14-dia. lens

Receiver

Emitter

21

13.7

67.8

68.5

18

25

29

43

6-dia. vinyl-insulated round cable with 3 conductors

insulator diameter: 1.3 mm)

Standard length: 2 m

Two, M4

25

TEACH button

Operation indicator (orange)

Stability indicator (green)

Teaching indicator (red/green)

M2.6

Operation

selector

Pre-wired Model

E3G-L73

Mounting

Holes

Standard Connector Model

E3G-L77

Note: All dimensions other than the

ones specified below are the

same as the corresponding

dimensions of the E3G-L73.

8

37

8

43

7

10.5 dia.

10

M12 Connector

ON-delay adjuster*

OFF-delay adjuster*

37

74

Two, M4

Two, 4.5-dia.

mounting holes

84.45

18

84.95

30

14

24.4

74

6

13.7

29

16

37

68

44

Operation indicator (orange)

Stability indicator (green)

Teaching indicator (red/green)

TEACH button

14-dia. lens

Receiver

Emitter

M2.6

Operation

selector

PF1/2 conduit: JIS B 0202

M2.6 nut

*The ON- or OFF-delay adjuster is not

available with the E3G-ML79.

Hexagonal nut

(Diagonal: 22)

Applicable cable:

6 to 8 dia.

Terminal Block Models

E3G-ML79

E3G-ML79T

Mounting Holes
