Axcelerator Family FPGAs

Re vi s i on 18

2-7

The maximum power dissipation allowed for Military temperature and Mil-Std 883B devices is specified

as a function of

θjc.

Timing Characteristics

Axcelerator devices are manufactured in a CMOS process, therefore, device performance varies

according to temperature, voltage, and process variations. Minimum timing parameters reflect maximum

operating voltage, minimum operating temperature, and best-case processing. Maximum timing

parameters reflect minimum operating voltage, maximum operating temperature, and worst-case

processing. The derating factors shown in Table 2-7 should be applied to all timing data contained within

this datasheet.

All timing numbers listed in this datasheet represent sample timing characteristics of Axcelerator devices.

Actual timing delay values are design-specific and can be derived from the Timer tool in Microsemi’s

Designer software after place-and-route.

Table 2-6 • Package Thermal Characteristics

Package Type

Pin Count

ja Still Air

ja 1.0m/s

ja 2.5m/s Units

Chip Scale Package (CSP)

180

N/A

57.8

51.0

°C/W

Plastic Quad Flat Pack (PQFP)

208

8.0

23.5

20.9

°C/W

Plastic Ball Grid Array (PBGA)

729

2.2

13.7

10.6

9.6

°C/W

Fine Pitch Ball Grid Array (FBGA)

256

3.0

26.6

22.8

21.5

°C/W

Fine Pitch Ball Grid Array (FBGA)

324

3.0

25.8

22.1

20.9

°C/W

Fine Pitch Ball Grid Array (FBGA)

484

3.2

20.5

17.0

15.9

°C/W

Fine Pitch Ball Grid Array (FBGA)

676

3.2

16.4

13.0

12.0

°C/W

Fine Pitch Ball Grid Array (FBGA)

896

2.4

13.6

10.4

9.4

°C/W

Fine Pitch Ball Grid Array (FBGA)

1152

1.8

12.0

8.9

7.9

°C/W

Ceramic Quad Flat Pack (CQFP)1

208

2.0

19.8

18.0

°C/W

Ceramic Quad Flat Pack (CQFP)1

352

2.0

17.9

16.1

14.7

°C/W

Ceramic Column Grid Array (CCGA)2

624

6.5

8.9

8.5

°C/W

Notes:

θjc for the 208-pin and 352-pin CQFP refers to the thermal resistance between the junction and the

bottom of the package.

θjc for the 624-pin CCGA refers to the thermal resistance between the junction and the top surface of the

package. Thermal resistance from junction to board (

jb) for CCGA 624 package is 3.4°C/W.

Table 2-7 • Temperature and Voltage Timing Derating Factors

(Normalized to Worst-Case Commercial, TJ = 70°C, VCCA = 1.425V)

VCCA

Junction Temperature

–55°C

–40°C

0°C

25°C

70°C

85°C

125°C

1.4 V

0.83

0.86

0.91

0.96

1.02

1.05

1.15

1.425 V

0.82

0.84

0.90

0.94

1.00

1.04

1.13

1.5 V

0.78

0.80

0.85

0.89

0.95

0.98

1.07

1.575 V

0.74

0.76

0.81

0.85

0.90

0.94

1.02

1.6 V

0.73

0.75

0.80

0.84

0.89

0.92

1.01

Notes:

1. The user can set the junction temperature in Designer software to be any integer value in the range of –

°C to 175°C.

2. The user can set the core voltage in Designer software to be any value between 1.4V and 1.6V.
