Am79C978
17
CONNECTION DIAGRAM (160 PQFP)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
NC
NC
IDSEL
AD23
VSSB
AD22
VDD_PCI
AD21
AD20
VDD
AD19
AD18
VSSB
AD17
VDD_PCI
AD16
C/BE2
VSS
FRAME
IRDY
VSSB
TRDY
VDD_PCI
DEVSEL
STOP
VDD
PERR
SERR
VSSB
PAR
VDD_PCI
C/BE1
AD15
VSS
AD14
AD13
VSSB
AD12
NC
NC
120
119
118
117
116
115
114
113
112
111
110
109
108
107
106
105
104
103
102
101
100
99
98
97
96
95
94
93
92
91
90
89
88
87
86
85
84
83
82
81
RX-
DVDDRX
RX+
DVSSX
TX-
DVDDTX
TX+
DVDDD
IREF
DVSSD
DVSSA
DVDDA
PHY_RST
DVDDA_HR
VSSB
VDDB
HRTRXP
VDDHR
HRTRXN
VSSHR
VDDCO
XTAL1
XTAL2
VSS
VDD
XCLK/XTAL
LED4
MDIO
VSSB
MDC
RXD3
RXD2
VDDB
RXD1
RXD0
VSS
NC
NC
NC
NC
Am79C978
22206B-3
