224
Am79C978
SWITCHING CHARACTERISTICS: BUS INTERFACE (CONTINUED)
10BASE-T Mode
Note: VOUT reflects output levels prior to 1:√2 transformer stage.
Power Supply Current
Symbol
Parameter Description
Test Conditions
Minimum
Maximum
Unit
VOUT
Output Voltage on TX± (peak)
1.55
1.98
V
VDIFF
Input Differential Squelch
Assert on RX± (peak)
300
520
mV
VDIFF
Input Differential De-Assert
Voltage on RX± (peak)
150
300
mV
IIX
Input Leakage Current
-300
300
µa
Symbol
Parameter Description
Test Conditions
Maximum
Unit
ICC
(1 Mbps)
1Mbps mode on TX± and RX±.
Outputs driving load.
VDD= Maximum
480
mA
ICC
(10 Mbps)
10BASE-T mode on TX± and RX±.
Outputs driving load.
VDD= Maximum
480
mA
