MODEL L SERIES

L Series

www.bitechnologies.com www.irctt.com www.welwyn-tt.com

General Note

TT electronics reserves the right to make changes in product specification without notice or liability.

All information is subject to TT electronics’ own data and is considered accurate at time of going to print.

© TT electronics plc

03.12

Ordering Information

Applicable Documents

MIL-R-83401 — Resistor Networks, Fixed, Film, General Specifications

MIL-STD-105 — Sampling Procedures and Tables for Inspection by Attributes

MIL-STD-202 — Test Methods for Electronic and Electrical Component Parts

L 08 5 S 331 / 471 F LF XX

Model Series

Number of Leads:

4 thru 14

Circuit Type:

3 = Isolated

1 = Bussed

5 = Dual Terminator

G3T = Ammo Pack, Steel Leads only

3 leads only attached to tape.*

M1 or M2 = Tube **

(No code used for standard bulk packaging.)

LF: RoHS Compliant

Tolerance Code:

F = ±1%

J = ±5%

(No code used for 2% standard.)

R2 Resistance Code:

(Add for -5 circuit only)

Resistance Code:

First 2 digits are significant.

Last digit denotes number of trailing zeros.

For "F" tolerance first 3 digits are significant.

Fourth digit denotes number of trailing zeros.

* Refer to Packaging for Automation section (Page A-3) for Ammo Pack capacity and dimensions.

** Refer to Packaging for Automation section (Page A-4) for M1 and M2 tube capacity and dimensions.
