Copyright © 2013 Future Technology Devices International Limited
32
FT240X USB 8-BIT FIFO IC Datasheet
Version 1.3
Document No.: FT_000626 Clearance No.:
FTDI# 259
9.2 SSOP-24 Package Markings
Figure 9.2 SSOP-24 Package Markings
Notes:
1. YYWW = Date Code, where YY is year and WW is week number
2. Marking alignment should be centre justified
3. Laser Marking should be used
4. All marking dimensions should be marked proportionally. Marking font should be using Greatek
standard font (Roman Simplex)
Line 1 – FTDI Logo
Line 2 – Date Code, Revision
Line 3 – Wafer Lot Number
Line 4 – FTDI Part Number
FT240XS
1
12
13
24
-B
