VNH7013XP-E
Package and packing information
Doc ID 022370 Rev 3
21/24
Table 16.
PowerSSO-36 TP mechanical data
Symbol
Millimeters
Min.
Typ.
Max.
A
2.15
2.47
A2
2.15
2.40
a1
0
0.1
b
0.18
0.36
c
0.23
0.32
D
10.10
10.50
E7.4
7.6
e0.5
e3
8.5
F2.3
G
0.1
H
10.1
10.5
h
0.4
k
0 deg
8 deg
L0.6
1
M4.3
N10 deg
O1.2
Q0.8
S2.9
T3.65
U1.0
X1
1.85
2.35
Y1
3
3.5
X2
1.85
2.35
Y2
3
3.5
X3
4.7
5.2
Y3
3
3.5
Z1
0.4
Z2
0.4
