ICS570A

Multiplier and Zero Delay Buffer

MDS 570A C

3

Revision 102700

Printed 11/14/00

Integrated Circuit Systems, Inc .• 525 Race Street • San Jose • CA •95126• (408)295-9800tel •www.icst.com

Electrical Specifications

Parameter

Conditions

Minimum

Typical

Maximum

Units

ABSOLUTE MAXIMUM RATINGS (Note 1)

ABSOLUTE MAXIMUM RATINGS (Note 1)

Supply Voltage, VDD

Referenced to GND

7

V

Inputs

Referenced to GND

-0.5

VDD+0.5

V

Clock Output

Referenced to GND

-0.5

VDD+0.5

V

Ambient Operating Temperature

ICS570M

0

70

°C

ICS570MI

-40

85

°C

Soldering Temperature

Max of 10 seconds

260

°C

Storage temperature

-65

150

°C

DC CHARACTERISTICS (VDD = 3.3V or 5.0V unless otherwise noted)

DC CHARACTERISTICS (VDD = 3.3V or 5.0V unless otherwise noted)

DC CHARACTERISTICS (VDD = 3.3V or 5.0V unless otherwise noted)

Operating Voltage, VDD

3

5.5

V

Input High Voltage, VIH, VDD=5V

ICLK, FBIN

2

V

Input Low Voltage, VIL, VDD=5V

ICLK, FBIN

0.8

V

Input High Voltage, VIH

S0, S1

VDD-0.5

V

Input High Voltage, VIM (mid-level)

S0, S1

VDD/2

V

Input Low Voltage, VIL

S0, S1

0.5

V

Output High Voltage, VOH, CMOS level

IOH=-4mA

VDD-0.4

V

Output High Voltage, VOH

IOH=-12mA

2.4

V

Output Low Voltage, VOL

IOL=12mA

0.4

V

IDD Operating Supply Current, 50 in, 100 out

No Load, 5.0V

22

mA

IDD Operating Supply Current, 50 in, 100 out

No Load, 3.3V

12

mA

Short Circuit Current

Each Output

±50

mA

Input Capacitance, S1, S0

5

pF

AC CHARACTERISTICS (VDD = 3.3V or 5.0V unless otherwise noted)

AC CHARACTERISTICS (VDD = 3.3V or 5.0V unless otherwise noted)

AC CHARACTERISTICS (VDD = 3.3V or 5.0V unless otherwise noted)

Input Frequency, ICLK (see table on page 2)

2.5

150

MHz

Output Clock Frequency, CLK

10

150

MHz

Skew of output clocks

Note 2

50

150

ps

Input skew, ICLK to FBIN Note 2

VDD=3.3V, CLK>10MHz

-500

500

ps

Input skew, ICLK to FBIN Note 2

VDD=3.3V, CLK<5MHz

-1.0

1.0

ns

Input skew, ICLK to FBIN Note 2

VDD=3.3V, CLK<10MHz

-750

750

ps

Input skew, ICLK to FBIN Note 2

VDD=5V, CLK<10MHz

-1.5

1.5

ns

Input skew, ICLK to FBIN Note 2

VDD=5V, CLK>10MHz

-1.0

1.0

ns

Output Clock Rise Time, 3.3V

0.8 to 2.0V, note 3

0.75

ns

Output Clock Fall Time, 3.3V

2.0 to 0.8V, note 3

0.75

ns

Output Clock Rise Time, 5V

0.8 to 2.0V, note 3

0.5

ns

Output Clock Fall Time, 5V

2.0 to 0.8V, note 3

0.5

ns

Output Clock Duty Cycle

at VDD/2

45

49 to 51

55

%

Notes

1. Stresses beyond these can permanently damage the device

2. Assumes clocks with same rise time, measured from rising edges at VDD/2.

3. With 27

Ω terminating resistor and 15 pF loads.
