18. PROGRAM DEVELOPMENT TOOLS

To develop programs for the

µPD6124A and 6600A, an assembler and an emulator for the µPD612X series are

available from I.C. Corp. For details, contact IC Corp.

IC Corporation

6th Barnet Gotanda Bldg.

1-9-5 Higashi-Gotanda, Shinagawa-ku

Tel. 03-3447-3793

Fax. 03-3440-5606

Caution

To develop the programs for the

µPD6124A and 6600A, use the µPD6124 because the µPD6124A and

6600A are not available as the target devices for assembly and emulation.

The upper limit of ROM addresses is different in the

µPD6124A/6600A and µPD6124. Make sure that

the program does not exceed 512 steps by checking the end address of the assembly listing after

assembling the program.

The mask option of the

µPD6124A/6600A is the same as that of the µPD6124.

19. ORDERING ROM CODE

<1> To generate the data required for ordering a mask ROM, after assembling the program, convert the HEX file

to a ROM file by using the PROM utility program "UPDPROM".

Caution

When using "UPDPROM" select "27256" for PROM TYPE.

<2> Confirm that the instruction ROM code data is stored in addresses 0 through 7D3H (3FFH in

µPD6600A) of

the PROM.

Also confirm that the mask option ROM code data are stored in addresses 7FF0H through 7FF2H.
