188 / 274 page  Mitsubishi microcomputers M16C / 62A Group SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER Timing (Vcc = 5V) 188 BCLK CSi ALE –4ns.min RD 25ns.max 0ns.min 4ns.min 4ns.min Hi–Z DB 0ns.min ADi BHE Read timing BCLK CSi ALE 25ns.max 0ns.min 4ns.min 4ns.min Hi-Z DB 40ns.max 4ns.min (tcyc/2–40)ns.min ADi BHE Write timing td(BCLK–AD) td(BCLK–ALE) th(BCLK–ALE) tSU(DB–RD) th(BCLK-AD) td(BCLK–WR) th(BCLK–DB) td(BCLK–RD) td(BCLK–ALE) 40ns.min tac1(RD–DB) Memory Expansion Mode and Microprocessor Mode (With no wait) WR,WRL, WRH td(BCLK–CS) 25ns.max tcyc th(BCLK–CS) th(RD–CS) 0ns.min 25ns.max th(BCLK–AD) th(RD–AD) 0ns.min th(BCLK–RD) 25ns.max th(RD–DB) td(BCLK–CS) 25ns.max th(BCLK–CS) tcyc th(WR–CS) 0ns.min td(BCLK–AD) 25ns.max 25ns.max th(BCLK–ALE) –4ns.min th(WR–AD) 0ns.min th(BCLK–WR) td(BCLK–DB) td(DB–WR) th(WR–DB) 0ns.min VCC = 5V Figure 1.23.4. VCC=5V timing diagram (3) |
|
