NJG1515AVB2

- 6 -

nELECTRICAL CHARACTERISTICS 5 [1.5GHz Rx Mode]

Common Condition:

PARAMETER

SYMBOL

CONDITIONS

MIN

TYP

MAX

UNITS

Frequency range 4

fin4

1477

-

1501

MHz

RX-ANT1

Insertion Loss

LOSS9

-

0.80

0.95

dB

RX-ANT2

Insertion Loss

-

0.80

0.95

dB

RX-EXT1

Insertion Loss

-

1.00

1.15

dB

RX-EXT2

Insertion Loss

-

0.80

0.95

dB

RX-ANT1 Isolation

ISL15

RX-ANT2, RX-EXT1,

18

22

-

dB

RX-ANT2 Isolation

ISL16

RX-ANT1, RX-EXT1,

19

24

-

dB

RX-EXT1 Isolation

ISL17

RX-ANT1, RX-ANT2,

23

28

-

dB

RX-EXT2 Isolation

ISL18

RX-ANT1, RX-ANT2,

17

22

-

dB

Pin at 1dB

compression point2

RX-ANT1, RX-ANT2,

RX-EXT1, RX-EXT2 passing

20

26

-

dBm

VSWR4

VSWR4

RX-ANT1, RX-ANT2, RX-EXT1,

RX-EXT2 passing

-

1.4

1.6

Switching time 4

TD4

CTL1~3

-

120

500

nsec

Tested on PCB circuit as shown below

Insertion loss of each connectors, striplines, and capacitors are excluded.

TX, RX, ANT1, ANT2, EXT1 and EXT2 are terminated to 50

Ω.

TER1 and TER2 are connected to GND through 5pFcapacitor.
