NJG1709KC1
- 24 -
nTYPICAL CHARACTERISTICS 2 (LNA+MIXER, f=1.9GHz, f
LO=1660MHz, with test circuit 2)
-50
-45
-40
-35
-30
-25
-20
1640
1650
1660
1670
1680
1690
LOCAL IN to RF IN Isolation
vs. LO Frequency
LO Frequency (MHz)
-35
-30
-25
-20
-15
-10
-5
1640
1650
1660
1670
1680
1690
LOCAL IN to IF OUT Isolation
vs. LO Frequency
LO Frequency (MHz)
IF OUT
M.N
M.N.
M.N
M.N.
M.N.
RF OUT
MIXER IN
RF IN
LOCAL IN
Port 1
50
Ω
Port 2
Condition
V
LNA=2.7V
V
MIX=VLO=2.7V
P
LO=-15dBm
Port1: LOCAL IN
Port2: IF OUT
Condition
V
LNA=2.7V
V
MIX=VLO=2.7V
P
LO=-15dBm
Port1: LOCAL IN
Port2: RF IN
IF OUT
M.N
M.N.
M.N
M.N.
M.N.
RF OUT
MIXER IN
RF IN
LOCAL IN
Port 1
Port 2
50
Ω
RF OUT – MIXER IN
Coaxial Cable
Z0=50 ohm, L=260 mm
RF OUT – MIXER IN
Coaxial Cable
Z0=50 ohm, L=260 mm
