background image
NJG1709KC1
- 26 -
nTEST CIRCUIT
1.5GHz BAND
1.9GHz BAND
Upper LOCAL
Lower LOCAL
PART ID
f
LO=1619MHz
P
LO=-15dBm
f
IF=130MHz
f
LO=1660MHz
P
LO=-15dBm
f
IF=240MHz
COMMENT
L1
12nH
10nH
TAIYO-YUDEN (HK1005)
L2
12nH
6.8nH
TAIYO-YUDEN (HK1005)
L3
10nH
5.6nH
TAIYO-YUDEN (HK1005)
L4
2.7nH
1.5nH
TAIYO-YUDEN (HK1005)
L5
18nH
3.9nH
TAIYO-YUDEN (HK1005)
L6
15nH
1.2nH
TAIYO-YUDEN (HK1005)
L7
82nH
47nH
TAIYO-YUDEN (HK1608)
L8
33nH
18nH
TAIYO-YUDEN (HK1005)
L9
22nH
18nH
TAIYO-YUDEN (HK1005)
L10
15nH
18nH
TAIYO-YUDEN (HK1005)
L11
8.2nH
8.2nH
TAIYO-YUDEN (HK1005)
C1
30pF
7pF
MURATA (GRM36)
C2
39pF
12pF
MURATA (GRM36)
C3
1000pF
1000pF
MURATA (GRM36)
C4
1000pF
1000pF
MURATA (GRM36)
C5
12pF
6pF
MURATA (GRM36)
C6
1000pF
1000pF
MURATA (GRM36)
C7
10pF
10pF
MURATA (GRM36)
C8
100pF
100pF
MURATA (GRM36)
C9
1000pF
1000pF
MURATA (GRM36)
C10
10pF
10pF
MURATA (GRM36)
C11
100pF
100pF
MURATA (GRM36)
R1
18
Ω
10
Ω
CHIP SIZE 1005
R2
18
Ω
-
CHIP SIZE 1005
PARTS LIST
