ML2035
8
TYPICAL APPLICATIONS
RECEIVE
LINE
INTERFACE
ML2003
ML2004
ML2008
ML2009
ATTENUATION
/GAIN
ML2031
ML2032
TONE
DETECTOR
TRANSMIT
LINE
INTERFACE
ML2035
TONE
GENERATOR
LOOPBACK
RELAY
ML2020
ML2021
LINE
EQUALIZER
µP
ML2003
ML2004
ML2008
ML2009
ATTENUATION
/GAIN
Figure 6. 4-Wire Termination Equipment.
Figure 7. Sine Wave Ratiometric to ±VCC/2.
5V
–5V
ML2035
VCC
GND
VOUT
0.1µF
VCC/2
VCC/2
0 TO 25kHz SINEWAVE
0.1µF
VSS
