MBR2060C

DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R601-083.D



PARAMETER

SYMBOL

RATINGS

UNIT

Peak Repetitive Reverse Voltage

60

V

Working Peak Reverse Voltage

60

V

DC Blocking Voltage

60

V

RMS Reverse Voltage

42

V

Average Forward Rectified Output

Per Leg

10

A

Total

20

Non-Repetitive Peak Forward Surge Current 8.3ms Single

half sine-wave

150

A

Typical Junction Capacitance

650

pF

Junction Temperature

-55~+150

°C

Storage Temperature

-55~+150

°C

Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. Pulse width≤300μs, duty cycle≤2%.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

60

°С/W

Junction to Case

TO-220/TO-263

3

°С/W

TO-220F/TO-220F1

5



ELECTRICAL CHARACTERISTICS

PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Instantaneous Forward Voltage Drop (Note 2)

0.80

V

0.70

0.95

0.85

Instantaneous Reverse Current (Note 2)

0.1

mA

15

Notes: 1. 2.0μs Pulse Width, f = 1.0KHz.

2. Pulse Test: Pulse Width=300µs, Duty Cycle≤　2.0%.
