background image
LXE1710 EVALUATION BOARD
USER GUIDE
Microsemi
Linfinity Microelectronics Division
11861 Western Avenue, Garden Grove, CA. 92841, 714-898-8121, Fax: 714-893-2570
Page 7
Copyright
© 2000
Rev. 1.1, 2000-12-01
ELECTRICAL CHARACTERISTICS
Unless otherwise specified, the following specifications apply over the operating ambient temperature 0°C<TA<70°C.
For test circuit, see LXE1710 Evaluation Board Schematic diagram.
PARAMETER
SYMBOL
TEST CONDITIONS
MIN.
TYP.
MAX
UNITS
Supply Voltage LX1710
VDD
7
15
V
Supply Current
IDD
VIN=15V, PO=38W, RL

THD+N=1%
3
A
Quiescent Current
IQ
VIN=15V, No Input
43
mA
VIN=15V, RL

10Hz to 22kHz
14
W
VIN=15V, RL

10Hz to 22kHz
25
W
Output Power
PO
VIN=15V, RL

10Hz to 22kHz
38
W
VIN=15V, fIN=1kHz, PO=10W
82
%
Efficiency
VIN=15V, fIN=1kHz, PO=20W
85
%
fIN=1kHz, PO=1W
0.05
%
Total Harmonic Distortion Plus
Noise
THD+N
fIN=20Hz to 20kHz, PO=1W
0.3
%
Signal-To-Noise Ratio
SNR
81
dBV
Power Supply Rejection Ratio
PSRR
VIN=15V, VRIPPLE=1VRMS,
10Hz to 10kHz
-70
dB
