Data Sheet

ADP2230

Rev. A | Page 9 of 18

Figure 15. Load Transient Response, VOUT = 1.2 V, Auto Mode, 50 mA to 250 mA

Figure 16. Load Transient Response, VOUT = 1.2 V, Auto Mode, 200 mA to 600 mA

Figure 17. Load Transient Response, VOUT = 1.8 V, Auto Mode, 10 mA to 110 mA

Figure 18. Load Transient Response, VOUT = 1.8 V, Auto Mode, 50 mA to 250 mA

Figure 19. Load Transient Response, VOUT = 1.8 V, Auto Mode, 200 mA to 600 mA

Figure 20. Load Transient Response, VOUT = 3.3 V, Auto Mode, 10 mA to 110 mA

LOAD CURRENT (100mA/DIV)

OUTPUT VOLTAGE (50mV/DIV)

AC-COUPLED

TIME (40µs/DIV)

LOAD CURRENT (200mA/DIV)

OUTPUT VOLTAGE (50mV/DIV)

AC-COUPLED

TIME (40µs/DIV)

LOAD CURRENT (50mA/DIV)

OUTPUT VOLTAGE (50mV/DIV)

AC-COUPLED

TIME (40µs/DIV)

LOAD CURRENT (100mA/DIV)

OUTPUT VOLTAGE (100mV/DIV)

AC-COUPLED

TIME (40µs/DIV)

LOAD CURRENT (200mA/DIV)

OUTPUT VOLTAGE (100mV/DIV)

AC-COUPLED

TIME (40µs/DIV)

LOAD CURRENT (50mA/DIV)

OUTPUT VOLTAGE (50mV/DIV)

AC-COUPLED

TIME (40µs/DIV)
