Data Sheet
ADP2230
Rev. A | Page 11 of 18
Figure 27. Startup, VOUT = 3.3 V, 800 mA
Figure 28. Short-Circuit Response
Figure 29. Typical PSM Operation, VOUT = 3.3 V, ILOAD = 50 mA, 150 mA
Figure 30. Typical PWM Operation, VOUT = 3.3 V, ILOAD = 400 mA
3
4
1
2
ENx PIN (5V/DIV)
OUTPUT VOLTAGE (5V/DIV)
INDUCTOR CURRENT (500mA/DIV)
SWx PIN (5V/DIV)
TIME (40µs/DIV)
3
4
1
2
VOUT1 = 1.2V (2V/DIV)
VOUT2 = 3.3V SHORTED TO GROUND
(2V/DIV)
INDUCTOR CURRENT (500mA/DIV)
SWx PIN (2V/DIV)
TIME (400ns/DIV)
1
3
4
SWx PIN (2V/DIV)
INDUCTOR CURRENT (200mA/DIV)
OUTPUT VOLTAGE (50mV/DIV)
AC-COUPLED
TIME (2µs/DIV)
1
3
4
SWx PIN (2V/DIV)
INDUCTOR CURRENT (200mA/DIV)
OUTPUT VOLTAGE (50mV/DIV)
AC-COUPLED
TIME (2µs/DIV)
