STCF07

Application information

Doc ID 16757 Rev 3

7/26

4

Application information

Note:

Represents a typical application schematic for an output current of 800 mA (max) in

continuous mode operation. For pulse/flash mode operation it is possible to increase the

maximum output current up to 1 A. If the battery voltage is higher than 3.1 V, the chip is

capable of delivering the maximum output current of up to 1 A in continuos mode.

Note:

The above-listed external components refer to a typical application. Operation of the

STCF07 is not limited to the use of these components.

Figure 3.

Application schematic diagram

VBAT

PVBAT

ENABLE

CSEL

FAULT

VLX1 VLX1

NTC

FB1

FB2

FB2S

VOUT

GND

PGND

C

IN

R

HC

R

LC

LED

NTC

VLX2

RX

R

X

C

OUT

Optional components

V

IN

L

VBAT

PVBAT

ENABLE

CSEL

FAULT

VLX1 VLX1

NTC

FB1

FB2

FB2S

VOUT

GND

PGND

C

IN

R

HC

R

LC

LED

NTC

VLX2

RX

R

X

C

OUT

Optional components

V

IN

L

Table 5.

List of external components

Component

Manufacturer

Part number

Value

Size

Welwyn

0.2

Ω

1206

KOA

0.16

Ω

1206

Tyco Electronics

CRL1220T1R8J

1.8

Ω

0805

TDK

C1608X5R0J106MT

10 µF

0603

TDK

C1608X5R0J475M

4.7 µF

0603

LTDK

2.2 µH / 1.4 A

3.5x3.8x1.4 mm

2.2 µH / 2.3 A

4.6x4.8x1.4 mm

NTC

MURATA

NCP18WF104J03RB

100 k

Ω

0805

Tyco Electronics

1-1879132-9

15 k

Ω

0402

LED

Luxeon

LXHL_PW09

1.

For 800 mA output current performance.

2.

For 1000 mA output current performance.
