B155

sProduct Specifications

Current rating

(Note1)

Voltage rating

AWG 20 to 24 : 3A

AWG 26

: 2A

Cable Size

AWG 28

: 1A

AWG 30

: 0.5A

250V AC

Storage Temperature Range

Storage Moisture Range

Operating Temperature Range

Operating Moisture Range

Item

Specification

Condition

1. Insulation Resistance

1000M ohms Min

500V DC

2. Withstanding voltage

No flashover or insulation breakdown.

650V AC/1 minute

3. Contact Resistance

30m ohms Max

100mA

4. Insertor/Extraction Force

MIN0.44N (45gf), MAX4.4N(450gf)

Measure at the square steel pin of 0.635±0.002mm

5. Vibration

No electrical discontinuity of 1µs or more

Frequency: 10 to 55 Hz, single amplitude of 0.75 mm, 2 hours in each of the 3 directions.

6. Humidity (Steady state) Contact resistance: 30m ohms max.Insulation resistance: 1000M ohms min. 96 hours at temperature of 40ç and humidity of 90% to 95%

7. Temperature Cycle

Contact resistance: 30m ohms max:Insulation resistance: 1000M ohms min.

(-55ç: 30 minutes ➝ 15 to 35ç: 2 to 3 minutes

8. Operating Life

Contact resistance: 30m ohms max.

Tin plating

: 30 cycles

Gold plating

: 50 cycles

9. Resistance to Soldering heat

No deformation of components affecting performance.

Flow: 250ç for 10 seconds

Manual soldering: 300ç for 3 seconds

Rating

Note 1: Includes temperature rise caused by current flow.

Note 2: The term "storage" refers to products stored for long period of time prior to mounting and use. Operating Temperature Range and

Humidity range covers non conducting condition of installed connectors in storage, shipment or during transportation.

Note: The whisker method is implemented for tin plating.

Current rating

(Note1)

Voltage rating

UL-CSA Safety Standard Standardized Value

AWG 20 to 22: 3A

Cable Size

AWG 24 to 28: 1A

AWG 30

: 0.5A

30V AC

Rating

sUL CSA Safety File No.

UL

: E52653

CSA

: LR95109

sMaterial

Product

Part

Material

Finish

Remarks

Socket

Insulator

Polyamide

White

UL94V-0

ID Contact for Socket

Contact

Phosphor copper

Tin plated or gold plated

––––––

Crimping Contact for Socket

Contact

Phosphor copper

Tin plated or gold plated

––––––

Pin Header

Insulator

Polyamide

White

UL94V-0

Contact

Brass

Tin plated or gold plated

––––––

In-line Plug

Insulator

Polyamide

White

UL94V-0

ID Contact for In-line Plug

Contact

Phosphor copper

Tin plated or gold plated

––––––

Crimping Contact for In-line Plug

Contact

Phosphor copper

Tin plated or gold plated

––––––
