GT14-2P/S-R 데이터시트(PDF) 6 Page - Hirose Electric

부품명 GT14-2P/S-R
상세설명  Coaxial cable connection of Antennas, Sensors, and Communication Trunk Lines
PDF  6 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  HIROSE [Hirose Electric]
홈페이지  http://www.hirose-connectors.com
Logo HIROSE - Hirose Electric

GT14-2P/S-R 데이터시트(HTML) 6 Page - Hirose Electric

  GT14-2P/S-R Datasheet HTML 1Page - Hirose Electric GT14-2P/S-R Datasheet HTML 2Page - Hirose Electric GT14-2P/S-R Datasheet HTML 3Page - Hirose Electric GT14-2P/S-R Datasheet HTML 4Page - Hirose Electric GT14-2P/S-R Datasheet HTML 5Page - Hirose Electric GT14-2P/S-R Datasheet HTML 6Page - Hirose Electric
Zoom Inzoom in Zoom Outzoom out
 6 / 6 page
background image
6
Part Number
CL No.
Item
Material
Finish
GT14W-2PP-HU
764-0001-0
Housing
PBT
Light gray
Connector Seal
Silicon rubber Compound
White
Double-Conductor Coaxial Cable - Waterproof Type
Part Number
CL No.
Material
Color
GT14W-2S-HU
764-0002-2
PBT
Light gray
Part Number
CL No.
Item
Material
Finish
GT14W-1P/S-4.8R
764-0003-5
Retainer
PBT
Dark gray
Wire seal
Silicon rubber compound
Light blue
Outer diameter of the cable must be within 4.7 to 4.0mm. Consult nearest HRS representative for other diameter.
F Connectors
Housing
M Connectors
Housing
BShown with inserted retainer
BFully mated connector assemblies
Retainers (used with GT14W-2S-HU and GT14W-2PP-HU)
