9 / 89 page

9/89

ADE3700

Pin Descriptions

108

OBB3

Input/Output

Output Port B: Blue Data 3

109

OBB2

Input/Output

Output Port B: Blue Data 2

110

OBB1

Input/Output

Output Port B: Blue Data 1

111

OBB0

Input/Output

Output Port B: Blue Data 0

OBA7

Output

Output Port A: Blue Data 7

OBA6

Output

Output Port A: Blue Data 6

OBA5

Output

Output Port A: Blue Data 5

OBA4

Output

Output Port A: Blue Data 4

OBA3

Output

Output Port A: Blue Data 3

OBA2

Output

Output Port A: Blue Data 2

OBA1

Output

Output Port A: Blue Data 1

OBA0

Output

Output Port A: Blue Data 0

INR

Input

Analog Video Port: Red Channel input

ING

Input

Analog Video Port: Green Channel input

INB

Input

Analog Video Port: Blue Channel input

HSYNC

Input

Horizontal (or Composite) Sync Input

DVDD33

Power

Digital 3.3V VDD

DVDD33

Power

Digital 3.3V VDD

DVDD33

Power

Digital 3.3V VDD

DVDD33

Power

Digital 3.3V VDD

106

DVDD33

Power

Digital 3.3V VDD

119

DVDD33

Power

Digital 3.3V VDD

DVDD18

Power

Digital 1.8V VDD

DVDD18

Power

Digital 1.8V VDD

DVDD18

Power

Digital 1.8V VDD

DVDD18

Power

Digital 1.8V VDD

117

DVDD18

Power

Digital 1.8V VDD

124

DVDD18

Power

Digital 1.8V VDD

DGND

Power

Digital Ground

DGND

Power

Digital Ground

DGND

Power

Digital Ground

DGND

Power

Digital Ground

DGND

Power

Digital Ground

DGND

Power

Digital Ground

DGND

Power

Digital Ground

DGND

Power

Digital Ground

107

DGND

Power

Digital Ground

Table 2: Pinout (Sheet 3 of 4)

LQFP128

Name

Type

Description
