background image
Pin Descriptions
ADE3700
10/89
116
DGND
Power
Digital Ground
118
DGND
Power
Digital Ground
125
DGND
Power
Digital Ground
33
CSYNC
Input
Composite Sync Input - for Sync On Green
36
AVDD33
Power
Analog 3.3V VDD
43
AVDD33
Power
Analog 3.3V VDD
50
AVDD33
Power
Analog 3.3V VDD
57
AVDD33
Power
Analog 3.3V VDD
46
AVDD18
Power
Analog 1.8V VDD
53
AVDD18
Power
Analog 1.8V VDD
60
AVDD18
Power
Analog 1.8V VDD
37
AGND
Power
Analog Ground
39
AGND
Power
Analog Ground
45
AGND
Power
Analog Ground
52
AGND
Power
Analog Ground
59
AGND
Power
Analog Ground
61
AGND
Power
Analog Ground
38
ADVDD18
Power
1.8V VDD
Table 2: Pinout (Sheet 4 of 4)
LQFP128
Name
Type
Description
