Data Sheet S15535EJ2V0DS

12

2.3

Electrical Specifications

Absolute Maximum Ratings

Parameter

Symbol

Condition

Rating

Unit

Power supply voltage

−0.5 to +4.6

V

Input voltage, 5 V buffer

3.0 V

−0.5 to +6.6

V

Input voltage, 3.3 V buffer

3.0 V

−0.5 to +4.6

V

Output voltage, 5 V buffer

3.0 V

−0.5 to +6.6

V

Output voltage, 3.3 V buffer

3.0 V

−0.5 to +4.6

V

Operating temperature

0 to

+70

°C

Storage temperature

−65 to +150

°C

Caution Product quality may suffer if the absolute maximum rating is exceeded even momentarily for any

parameters. That is, the absolute maximum ratings are rated values at which the product is on the

verge of suffering physical damage, and therefore the product must be used under conditions

that ensure that the absolute maximum ratings are not exceeded.

The ratings and conditions indicated for DC characteristics and AC characteristics represent the

quality assurance range during normal operation.

Recommended Operating Ranges

Parameter

Symbol

Condition

MIN.

TYP.

MAX.

Unit

Operating voltage

3.0

3.3

3.6

V

High-level input voltage

3.3 V High-level input voltage

2.0

V

5.0 V High-level input voltage

2.0

5.5

V

Low-level input voltage

3.3 V Low-level input voltage

0

0.8

V

5.0 V Low-level input voltage

0

0.8

V
