ASPI-1306S

ELECTRICAL SPECIFICATIONS:

30332 Esperanza, Rancho Santa Margarita, California92688

tel 949-546-8000| fax 949-546-8001| www.abracon.com

Revised: 07.25.13

Visit www.abracon.com for Terms & Conditions of Sale

SMD SHIELDED POWER INDUCTOR

FEATURES:

APPLICATIONS:

OPTIONS AND PART IDENTIFICATION

18.5 x 15.2 x 7.6 mm

ABRACON IS

CERTIFIED

ABRACON IS

ISO9001:2008

CERTIFIED

• Low radiation shielded architecture

• Large pads for good PCB mounting

• Low DCR, suitable for large currents

• High Energy storage

• Portable communication equipment

• OA equipment

• LCD, DVD, modem, set-top box

• DC/ DC converter

.

Pb RoHS

Compliant

PART NUMBER

INDUCTANCE

(uH) ±20%

DCR(Ω)

max

Isat (A)

max

Irms (A)

max

ASPI-1306S-100M

10

0.0400

8.00

3.90

ASPI-1306S-150M

15

0.0480

7.00

3.40

ASPI-1306S-220M

22

0.0590

6.00

3.10

ASPI-1306S-330M

33

0.0750

5.00

2.80

ASPI-1306S-470M

47

0.0970

4.00

2.40

ASPI-1306S-680M

68

0.1380

3.00

2.00

ASPI-1306S-101M

100

0.2070

2.40

1.70

ASPI-1306S-151M

150

0.2930

2.10

1.30

ASPI-1306S-221M

220

0.4700

1.90

1.10

ASPI-1306S-331M

330

0.7800

1.10

0.86

ASPI-1306S-471M

470

0.9750

0.90

0.60

ASPI-1306S-681M

680

1.4000

0.96

0.64

ASPI-1306S-102M

1000

2.0100

0.80

0.53

Test Conditions

Inductance: 100kHz, 0.1V

Isat: ∆L/L (initial) ≥ -10%

Irms: ∆T ≤ 40˚C

-40˚C to +85˚C

+25˚C

ASPI-1306S -

-

Inductance Code

Please refer to the

table above

Tolerance %

M: ± 20%

Packaging

T: Tape and Reel

(250pcs / reel)

ASPI-1306S
