ELECTRICAL SPECIFICATION CHART

ASPI-1306S

30332 Esperanza, Rancho Santa Margarita, California92688

tel 949-546-8000| fax 949-546-8001| www.abracon.com

Revised: 07.25.13

Visit www.abracon.com for Terms & Conditions of Sale

SMD SHIELDED POWER INDUCTOR

18.5 x 15.2 x 7.6 mm

ABRACON IS

CERTIFIED

ABRACON IS

ISO9001:2008

CERTIFIED

Pb RoHS

Compliant

Dimension: mm

Materials

Part Name

Material

Core

Fe2O3

NiO

CuO

MgO

ZnO

MnO2

Enamelled Wire

Copper

Modified Polyester Resin

Base

Copper

Iron

Zinc

Tin

COF

PURE Tin PLATING

DIM.

TOL.

12.7

±0.2

7.62

Max.

15.24

Max.

18.54

Max.

2.92

REF.

12.45

REF.

2.79

REF.

Item

mark

Temperature rise gradient

3oC/sec (max)

Heating time

Tsoak

50s ～ 150s

Heating temperature

120oC～180oC

Time over 217oC

70 sec

Time within 5oC of actual peak temperature

10～30 sec

Peak temperature

Tpeak

250 ( +0 / -5oC )

Time 25oC to peak Temperature

6 minutes max.

Temperature(°C)

Time (sec)

Tpeak

Tsoak

25°C

Time 25°C to peak

REFLOW PROFILE:
