MB-0278-2

JAE PMK Div. Proprietary. Copyright © 2015, Japan Aviation Electronics Industry, Ltd.

2/5

General Specifications

Items

Specifications and Performance

Operating Temperature

-40 Deg. C to 85 Deg. C

Applicable Cable

-

7.0mm (Standard Diameter) (FO-BD2-P Plug)

-

5.86mm to 7.2 (FO-BD2-P-V2 Plug)

-

8.5mm to 10.0 (FO-BD2-P-V4 Plug)

Repeated Mating

500 times

Cable Clamp Strength

100N min.

(when each plug is applicable maximum cable diameter)

Dustproof and Waterproof

Performance

IP67 (When mated)

Corrosion Resistance

720 hours of salt spray.

Materials and Finishes

Component

Material / Finish

Shell

Zinc alloy / chromium plating (Note 1)

O Ring

Synthetic rubber

■ Receptacle: FO-BD2-R

Note 1: Chromium plating: chromium plating (hexavalent chromium free) over nickel over copper.

Component

Material / Finish

Coupling Nut

Zinc alloy / chromium plating (Note 1)

Barrel

Synthetic resin

Ground Nut

Synthetic resin

Bushing

Synthetic rubber

O Ring

Synthetic rubber

■ Plug: FO-BD2-P, FO-BD2-P-V2, FO-BD2-P-V4

Component

Material / Finish

Cap

Synthetic resin

■ Waterproof Cap for Receptacle (without wire rope): FO-BD2-RCAP
