5
Applications
5.1
Measurement Settings and Use Case Examples
Table 10
Measurement Settings and Use Case Examples (TBD)
Use Case
Performance
Pressure Register
Configuration
Address: 0x06
Temperature
Register
Configuration
Address: 0x07
Other
Weather Station (Low power)
5 Pa precision.
1 pr sec.
3 uA
0x01
0x80
Start
background
measurements
(addr 0x08)
Indoor navigation (Standard
precision, background mode)
10 cm precision.
2 pr sec.
22 uA
0x14
0x90
Enable P shift
(addr 0x09)
Start
background
measurements
(addr 0x08)
Sports (High precision, high
rate, background mode)
5 cm precision
4 pr sec.
200 uA
0x26
0xA0
Enable P shift
(addr 0x09)
Start
background
measurements
(addr 0x08)
DPS310 - Digital Pressure Sensor
Digital Barometric Pressure Sensor for Portable Devices
Applications
17
V1.0
2016-09-05
