W.FL Series

■Receptacle

0.3

0.85

0.25

0.3

2

1.7

SIG

GND

BRecommended PCB

mounting pattern

GND

No conductive traces in this area

2.6

1.4

0.5

SIG

All dimensions: mm

Note: The land pattern is the same as that of the

X.FL, W.FL2 series connectors.

Embossed Carrier Tape Dimensions

28

24

Unreeling direction

Unreeling direction

(W.FL-R-SMT-1(60) 8mm pitch)

(W.FL-R-SMT-1(80) 4mm pitch)

Reel Dimensions

2

13.5

A

Material

：

Part No.

HRS No.

Packaging

RoHS

W.FL-R-SMT-1(60)

331-0482-6 60

Reel (5,000 pcs/reel)

Yes

W.FL-R-SMT-1(80)

331-0482-6 80

Reel (10,000 pcs/reel)

Embossed Carrier Tape Dimensions(IEC 60286-3 compliant)
