Product family data sheet

Cree, Inc.

4600 Silicon Drive

Durham, NC 27703

USA Tel: +1.919.313.5300

PRoDuCt DEsCRiPtion

builds on the breakthrough performance

of the original MK-R by enabling

high-voltage driver solutions while

providing a small, uniform, single point

source for precise optical control. The

MK-R2 shares the same mechanical

footprint as the original MK-R, providing

customers with a seamless upgrade path

and shortening the LeD luminaire and

retrofit lamp design cycle.

MK-R2 LeDs are designed for high-output,

directional lighting applications and

are the ideal replacement for lighting

applications that currently use inefficient

halogenlamps.MK-R2LeDsareoptimized

for use in track, accent, lamp retrofit,

downlighting and other applications

where color quality, consistency and

optical control are required.

FEAtuREs

• Available in 4-step and 2-step

EasyWhite bins at 2700 K & 3000 K,

80-CRI minimum

• Maximum drive current: 420 mA

• Low thermal resistance: 1.7 °C/W

• Maximum junction temperature:

150 °C

• Binned at 85 °C

• Viewing angle: 120°

• Unlimited floor life at

≤ 30 ºC/85% RH

• Reflow solderable - JEDEC

J-STD-020C

• electrically neutral thermal path

• RoHS and REACh compliant

(E349212)

tAbLE oF ContEnts

Characteristics ........................................2

Flux Characteristics, Standard Order

Codes and Bins .......................................2

Relative Spectral Power Distribution .....3

Relative Flux vs. Junction Temperature.3

electrical Characteristics........................4

Relative Flux vs. Current .........................4

Relative Chromaticity vs. Current...........5

Relative Chromaticity vs. Temperature..5

Typical Spatial Distribution.....................6

Thermal Design.......................................6

Performance Groups - Brightness .........7

Performance Groups - Chromaticity......7

Cree easyWhite® Bins Plotted on the

1931 CIE Color Space.............................8

Bin and Order Code Formats..................8

Reflow Soldering Characteristics...........9

Notes .....................................................10

Mechanical Dimensions .......................12

Tape and Reel........................................13

Packaging..............................................14
