U74LVC09A
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
2 of 5
www.unisonic.com.tw
QW-R126-043 .A
PIN CONFIGURATION
7
6
5
4
3
2
1
12
11
10
8
9
13
14
1A
1B
1Y
2A
2B
2Y
VCC
4B
4Y
3A
3B
4A
GND
3Y
FUNCTION TABLE (each gate)
INPUT(nA)
INPUT(nB)
OUTPUT(nY)
L
L
Z
L
H
Z
H
L
Z
H
H
L
H = High voltage level
L = Low voltage level
Z = High-impedance OFF-state
LOGIC DIAGRAM (Positive Logic)
Logic symbol
IEC logic symbol
