UNISONIC TECHNOLOGIES CO., LTD

U74LVC09A

CMOS IC

www.unisonic.com.tw

1 of 5

Copyright © 2016 Unisonic Technologies Co., Ltd

QW-R126-043 .A

QUAD 2-INPUT NAND GATE

WITH OPEN-DRAIN OUTPUT



DESCRIPTION

The U74LVC09A provides four 2-input NAND functions.The

outputs are open-drain and can be connected to other open-drain

outputs to implement active-LOW wired-OR or active-HIGH

wired-AND functions.

Inputs can be driven from either 3.3V or 5.5V devices.This

feature allows the use of these devices as translators in mixed 3.3V

and 5V applications.



FEATURES

* Operate From 1.65V to 5.5V

* Input Accept Voltages to 5.0V

* Partial-Power-Down Mode Operation

* Max tpd is 3.6ns at 3.3V



ORDERING INFORMATION

Ordering Number

Package

Packing

U74LVC09AG-S16-R

SOP-16

Tape Reel



MARKING
