background image
UU9792
Preliminary
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
4 of 15
www.unisonic.com.tw
QW-R125-047.a
ABSOLUTE MAXIMUM RATINGS
PARAMETER
SYMBOL
RATINGS
UNIT
Power Supply Voltage
VDD
-0.5 ~ +7.0
V
Power Supply for LCD driving
VLCD
-0.5 ~ VDD
V
Input voltage range
VIN
-0.5 ~ VDD+0.5
V
Operation temperature
TOPR
-40 ~ +85
°C
Storage temperature range
TSTG
-55 ~ +125
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
STANDARD OPERATING CONDITIONS
PARAMETER
SYMBOL
MIN
TYP
MAX
UNIT
Power Supply
VDD
2.5
5.5
V
Power Supply for LCD driving
VLCD
2.5
5.5
V
Operating Temperature Range
TOPR
-40
85
°C
ELECTRICAL CHARACTERISTICS
DC Characteristics
(VDD=2.5 ~ 5.5V, VLCD=2.5 ~ 5.5V, VSS=0V, TA= -40 ~ 85°C, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
“H” level input voltage
VIH
SDA SCL
0.7×VDD
VDD
V
“L” level input voltage
VIL
SDA SCL
VSS
0.3×VDD
V
Standby current
IST
Display off Oscillation off
5
uA
Operation current
IDD1
VDD=3.3v, TA=25°C, Power save
mode1, FR=Power save model1,
1/3Bias, Frame inverse
80
uA
Frame frequency
fCLK
VDD=3.3V
80
Hz
SCL cycle time
tSCL
2.5
us
SEG
3.5
KΩ
LCD Driver on resistance
COM
RON
ILOAD=±10uA
3.5
KΩ
