FUNCTION DESCRIPTIONS (Cont.)

OSCILLATOR

There are two kinds of clock for logic and analog circuit; from internal oscillator circuit or external clock.

When using external clock mode, it has to input external clock from OSCIN terminal after Set IC operation

(ICSET) terminal.

OSCIN

VSS

UU9792

OSCIN

UU9792

Clock input

Internal oscillator circuit mode

External clock input mode

LCD Driver Bias Circuit

This device generates LCD driving voltage with on-chip Buffer AMP.

And it can drive LCD at low power consumption.

1/3 Bias or 1/2 Bias can set in Mode Set command.

Line and frame inversion can set in DISCTL command



COMMAND

Description List of Command / Function

Command

Function

1

Address set(ADSET)

DDRAM address setting(00-22h)

2

EVR set (EVRSET)

EVR setting(0-31)

3

Display Control(DISCTL)

Frame Frequency, Power save mode setting

4

IC operation set (ICSET)

LCD drive mode, software reset, display on/off

5

All pixel Control(APCTL)

All pixel control during display ON
