 3 / 23 page
background image
Data Sheet
HMC557A
Rev. C | Page 3 of 23
ELECTRICAL SPECIFICATIONS
2.5 GHz TO 5.0 GHz FREQUENCY RANGE
TA = 25°C, IF = 100 MHz, LO drive = 15 dBm. All measurements performed as a downconverter with the upper sideband selected, unless
otherwise noted.
Table 1.
Parameter
Min
Typ
Max
Unit
OPERATING CONDITIONS
RF Frequency Range
2.5
5.0
GHz
LO Frequency Range
2.5
5.0
GHz
IF Frequency Range
DC
3
GHz
PERFORMANCE
Conversion Loss
8
10.5
dB
Noise Figure, Single Sideband (SSB)
8
dB
LO to RF Isolation
40
50
dB
LO to IF Isolation
26
35
dB
RF to IF Isolation
20
dB
Input Third-Order Intercept (IP3)
14
18
dBm
Input Second-Order Intercept (IP2)
55
dBm
Input Power for 1 dB Compression (P1dB)
10
dBm
RF Port Return Loss
10
dB
LO Port Return Loss
8
dB
5.0 GHz TO 7.0 GHz FREQUENCY RANGE
TA = 25°C, IF = 100 MHz, LO drive = 15 dBm. All measurements performed as a downconverter with the upper sideband selected, unless
otherwise noted.
Table 2.
Parameter
Min
Typ
Max
Unit
OPERATING CONDITIONS
RF Frequency Range
5.0
7.0
GHz
LO Frequency Range
5.0
7.0
GHz
IF Frequency Range
DC
3
GHz
PERFORMANCE
Conversion Loss
8.5
10.5
dB
Noise Figure, Single Sideband (SSB)
8.5
dB
LO to RF Isolation
37
43
dB
LO to IF Isolation
25
33
dB
RF to IF Isolation
25
dB
Input Third-Order Intercept (IP3)
14
18
dBm
Input Second-Order Intercept (IP2)
55
dBm
Input Power for 1 dB Compression (P1dB)
10
dBm
RF Port Return Loss
12
dB
LO Port Return Loss
12
dB
