4 / 23 page

HMC557A

Data Sheet

Rev. C | Page 4 of 23

ABSOLUTE MAXIMUM RATINGS

Table 3.

Parameter

Rating

RF Input Power

25 dBm

LO Input Power

27 dBm

Channel Temperature

175°C

Continuous PDISS (T = 85°C), Derate

10.81 mW/°C Above 85°C)

972 mW

Thermal Resistance (Channel to Ground Pad)

92.5°C/W

Maximum Peak Reflow Temperature

260°C

Storage Temperature Range

−65°C to +150°C

Operating Temperature Range

−40°C to +85°C

ESD Sensitivity, Human Body Model (HBM)

1000 V (Class 1C)

Stresses at or above those listed under Absolute Maximum

Ratings may cause permanent damage to the product. This is a

stress rating only; functional operation of the product at these

or any other conditions above those indicated in the operational

section of this specification is not implied. Operation beyond

the maximum operating conditions for extended periods may

affect product reliability.

ESD CAUTION
