Data Sheet

AD8237

Rev. 0 | Page 7 of 28

ABSOLUTE MAXIMUM RATINGS

Table 4.

Parameter

Rating

Supply Voltage

6 V

Output Short-Circuit Current Duration

Indefinite

Maximum Voltage at −IN, +IN, FB, or REF1

+V

Minimum Voltage at −IN, +IN, FB, or REF1

−V

Storage Temperature Range

−65°C to +150°C

Junction Temperature Range

−65°C to +150°C

ESD

Human Body Model

8 kV

Charge Device Model

1.25 kV

Machine Model

0.2 kV

expected, place resistors in series with the inputs to limit the current to 5 mA.

Stresses above those listed under Absolute Maximum Ratings

may cause permanent damage to the device. This is a stress

rating only; functional operation of the device at these or any

other conditions above those indicated in the operational

section of this specification is not implied. Exposure to absolute

maximum rating conditions for extended periods may affect

device reliability.

THERMAL RESISTANCE

Table 5.

Package

θ

JA

Unit

8-Lead MSOP, 4-Layer JEDEC Board

145.7

°C/W

ESD CAUTION
