STLC2500

2/23

3

QUICK REFERENCE DATA

VDD_IO_x means VDD_IO_A, VDD_IO_B. (See also table 13 subsection Power supply.)

3.1

Absolute Maximum Ratings

The Absolute Maximum Rating (AMR) corresponds to the maximum value that can be applied without

leading to instantaneous or very short-term unrecoverable hard failure (destructive breakdown).

Table 2. Absolute Maximum Ratings

3.2

Operating Ranges

Operating ranges define the limits for functional operation and parametric characteristics of the device.

Functionality outside these limits is not implied.

Table 3. Operating ranges

(*) The chip will be characterized from 2.62 [V] up to 2.9 [V].

(**) The chip will be characterized up to 2.9 [V].

3.3

I/O specifications

The I/Os comply with the EIA/JEDEC standard JESD8-B.

Table 4. DC Input specification (all digital I/Os except system clock)

Table 5. DC Output specification

Note: X is the source/sink current under worst-case conditions according to the drive capabilities (see section 5)

Symbol

Parameter

Min.

Max.

Unit

VDD_HV

Regulator input supply voltage

4.0

V

VDD_IO_x

Supply voltage I/O

4.0

V

-0.3

0.3

V

Input voltage of any digital pin

4.0

V

Storage temperature

-65

+150

°C

Lead temperature <10s

+250

°C

Symbol

Parameter

Min.

Typ.

Max.

Unit

Operating ambient temperature

-40

+85

VDD_HV

Regulator input supply voltage

2.75

V

VDD_IO_A

Supply voltage for I/O

1.65

V

VDD_IO_B

Supply voltage for I/O

1.35

V

Symbol

Parameter

Min.

Typ.

Max.

Unit

Low Level input voltage

0.35 *

VDD_IO_x

V

High Level input voltage

0.65 *

VDD_IO_x

V

Schmitt trigger hysteresis

0.4

0.5

0.6

V

Symbol

Parameter

Condition

Min.

Typ.

Max.

Unit

Low Level output voltage

0.15

V

High Level output voltage

VDD_IO_x

- 0.15

V
