FT260Q-R datasheet(2/61 Pages) FTDI

2 / 61 page

FT260 HID-CLASS USB TO UART/I2C BRIDGE IC

Version 1.1

Document No.: FT_001272 Clearance No.: FTDI#484

Typical Applications



HID class Device controller



USB to HID-over-I2C Bridge



USB to I2C master controller



USB to RS232/RS422/RS485 Converters



Interfacing MCU/PLD/FPGA based designs to

USB



USB Instrumentation

1.1

Driver Support

The USB Human Interface Device (HID) class is natively supported by most operation systems. A custom

driver is not required to be installed for the FT260.



Windows 10 32, 64-bit



Windows 8.1 32, 64-bit



Windows 8 32, 64-bit



Windows 7 32, 64-bit



Windows Vista and Vista 64-bit



Windows XP and XP 64-bit



Windows CE 4.2, 5.0, 5.2, 6.0



Windows Server 2008, 2003, 2000



Windows Embedded Operating Systems



Mac OS X



Linux



Android

1.2

Part Numbers

Part Number

Package

FT260Q-x

28 Pin WQFN

FT260S-x

28 Pin TSSOP

Note: Packing codes for x is:

- R: Taped and Reel, 2,500pcs per reel

- T: Tray packing, 490pcs per tray (WQFN only)

- U: Tube packing, 50pcs per tube (TSSOP only)

For example: FT260Q-R is 2,500pcs taped and reel packing
