 33 / 61 page
background image
Copyright © Future Technology Devices International Limited
33
FT260 HID-CLASS USB TO UART/I2C BRIDGE IC
Version 1.1
Document No.: FT_001272 Clearance No.: FTDI#484
6.4
USB Characteristics
Parameter
Description
Minimum
Typical
Maximum
Units
Conditions
DC Characteristics
URo
Output impedance
3.5
7
14
Ω
URpu
Internal Pull Up
resistance
0.976
1.24
1.574
Ω
UVOH
High level Output on DP
and DM
2.8
V
UVOL
Low level Output on DP
and DM
0.3
V
AC Characteristics
UTrise
Rise Time on DP/DM
4
10
20
ns
UTfall
Fall Time on DP/DM
4
10
20
ns
UVcr
Cross point
1.3
2.0
V
UVth
Single-ended receiver
threshold
0.8
2.0
V
Table 6.7 USB I/O Pin (DP, DM) Characteristics
