AMS00x • Embedded Bluetooth Low Energy Solution

Electrical Specifications, Section 3

ADS-MS00x-107R • Preliminary Data Sheet

Page | 4

©2014-2015 ACKme Networks. http://ack.me

September 14, 2015

Environmental Conditions

Table 4. Recommended Environmental Conditions

Characteristic

Note

Min.

Max.

Unit

Ambient Temperature

-30

+85

°C

Relative Humidity

Non-condensing (operating)

–

85

%

3.3 Power Consumption

The AMS00x automatically adjusts power dissipation based on user activity to minimize power usage. The power

consumption in each state, and for each version of the module, is specified in Table 5.

Table 5. Power Consumption (3.0V, 25°C)

Operational State

Note

Typical

Unit

BLE Chip (0.65 µA) + Serial Flash (1 µA)

1.65

µA

Sleep

Wake in <5ms

12.0

µA

AMS001

Active Receive

Receiver enabled and operating at 100% duty cycle

12.8

mA

Transmitter enabled and operating at 100% duty cycle

10.8

mA

AMS002

Active Receive

Receiver enabled and operating at 100% duty cycle

26.6

mA

Transmitter enabled and operating at 100% duty cycle

22.0

mA

Notes:

1. Requires 10K pullup resistor on module pin 6. See 6.5.1, UART Application for Configuration and Streaming

2. RF transmit power = 0dBm
