Temperature sensor registers

Note:

In all temperature register formats bits 0 and bits 1 are used when the resolution is more

than 10 bits. These registers show temperature data for the default 10 bits.

4.5

Manufacturer ID register (read-only)

The manufacturer’s ID (programmed value 104Ah) in this register is the STMicroelectronics

Identification provided by the Peripheral Component Interconnect Special Interest Group

(PCiSIG).

Table 19. Critical temperature register format

Sign

MSB

LSB(1)

Bit

Bit(2)

Bit

Bit(3)

Bit(4)

000

Critical temperature trip point

1. Bit 2 is LSB for default 10-bit mode.

2. If critical trip lockout bit (bit 7 of configuration register in Table 10) is set, then this register becomes read-only.

3. Depending on status of the resolution register, bit 1 may display 0.125 °C value.

4. Depending on status of the resolution register, bit 0 may display 0.0625 °C value.

Table 20. Manufacturer ID register (read-only)

Bit 15

Bit 14

Bit 13

Bit 12

Bit 11

Bit 10

Bit 9

Bit 8

00010000

Bit 7

Bit 6

Bit 5

Bit 4

Bit 3

Bit 2

Bit 1

Bit 0

01001010
