background image
ST7DALIF2
Electrical characteristics
157/171
20.11.1
Amplifier output offset variation
The offset is quite sensitive to temperature variations. In order to ensure a good reliability in
measurements, the offset must be recalibrated periodically i.e. during power on or whenever
the device is reset depending on the customer application and during temperature variation.
The table below gives the typical offset variation over temperature:
Table 91.
Amplifier characteristics
Symbol
Parameter
Conditions(1)
1.
Data based on characterization results over the whole temperature range, not tested in production.
Min
Typ
Max
Unit
VDD(AMP)
Amplifier operating voltage
3.6
5.5
V
VIN
Amplifier input voltage(2)
2.
Please refer to the Application Note AN1830 for details of TE% vs Vin.
VDD=3.6 V
0
350
mV
VDD=5 V
0
500
VOFFSET
Amplifier output offset
voltage(3)
3.
Refer to the offset variation in temperature below
VDD=5 V
200
mV
VSTEP
Step size for monotonicity(4)
4.
Monotonicity guaranteed if VIN increases or decreases in steps of min. 5 mV.
VDD=3.6 V
3.5
mV
VDD=5 V
4.89
Linearity
Output Voltage Response
Linear
Gain factor
Amplified Analog input
Gain(5)
5.
For precise conversion results it is recommended to calibrate the amplifier at the following two points:
- Offset at VINmin = 0V
- Gain at full scale (for example VIN=430 mV)
8
Vmax
Output Linearity Max Voltage V
INmax = 430 mV,
VDD=5 V
3.65
3.94
V
Vmin
Output Linearity Min Voltage
200
mV
Table 92.
Amplifier offset variation over temperature
Typical offset variation (LSB)
Unit
-45
-20
+25
+90
°C
-12
-7
-
+13
LSB
