CS7654

CbG Coefficient Register (15h at SA 0x34h)

Color separation and color space conversion coefficient.

YB Coefficient Register (16h at SA 0x34h)

Color separation and color space conversion coefficient.

CrB Coefficient Register (17h at SA 0x34h)

Color separation and color space conversion coefficient.

CbB Coefficient Register (18h at SA 0x34h)

Color separation and color space conversion coefficient.

Slave Data Hold Register (19h at SA 0x34h)

When an external I2C controller initiates a register read from a slave device on the secondary I2C bus through

CS7654, the returned data is placed in this register. The external controller may then read the data from the Slave

Data Hold register. This register is read only.

EPROM Count Low Byte Register (1Ah at SA 0x34h)

Lower byte of the number of triple-bytes to be read from EPROM upon reset of CS7654. This register is read only.

EPROM Count High Byte Register (1Bh at SA 0x34h)

Upper byte of the number of triple-bytes to be read from EPROM upon reset of CS7654. This register is read only.

Version (Major) Register (1Ch at SA 0x34h)

The major version register (device ID) in the CS7654 is assigned the value FDh. This register is read only.

Version (Minor) Register (1Dh at SA 0x34h)

The minor version register in CS7654 rev A. is assigned the value 00h. With each minor revision the value is in-

creased by 1. This register is read only.

765

4321

CbG7

CbG6

CbG5

CbG4

CbG3

CbG2

CbG1

CbG0

R/W

76543210

YB7

YB6

YB5

YB4

YB3

YB2

YB1

YB0

R/W

76543210

CrB7

CrB6

CrB5

CrB4

CrB3

CrB2

CrB1

CrB0

R/W

76543210

CbB7

CbB6

CbB5

CbB4

CbB3

CbB2

CbB1

CbB0

R/W
