CS7654
51
Configuration Control 11 (3Bh at SA 0x34h)
This register contains the 8 LSBs of the EEPROM start address used when the SKIP bit is set (bit 1 register 42h
at
SA 0x34h) and the Configuration Index Register (43h at SA 0x34h) is set to 05h.
Configuration Control 12 (3Ch at SA 0x34h)
This register contains the 3 MSBs of the EEPROM address used when the SKIP bit is set (bit 1 register 42h
at SA
0x34h) and the Configuration Index Register (43h at SA 0x34h) is set to 06h.
Configuration Control 13 (3Dh at SA 0x34h)
This register contains the 8 LSBs of the EEPROM start address used when the SKIP bit is set (bit 1 register 42h
at
SA 0x34h) and the Configuration Index Register (43h at SA 0x34h) is set to 06h.
Configuration Control 14 (3Eh at SA 0x34h)
This register contains the 3 MSBs of the EEPROM address used when the SKIP bit is set (bit 1 register 42h
at SA
0x34h) and the Configuration Index Register (43h at SA 0x34h) is set to 07h.
Configuration Control 15 (3Fh at SA 0x34h)
This register contains the 8 LSBs of the EEPROM start address used when the SKIP bit is set (bit 1 register 42h
at
SA 0x34h) and the Configuration Index Register (43h at SA 0x34h) is set to 07h.
Jump Control 0 (40h at SA 0x34h)
This register contains the 3 MSBs of the EEPROM address used when the JUMP bit is set (bit 2 register 42h
at SA
0x34h).
765
4321
0
SKP57
SKP56
SKP55
SKP54
SKP53
SKP52
SKP51
SKP50
R/W
765
4321
0
res
res
res
res
res
SKP610
SKP69
SKP68
Reserved
R/W
765
4321
0
SKP67
SKP66
SKP65
SKP64
SKP63
SKP62
SKP61
SKP60
R/W
765
4321
0
res
res
res
res
res
SKP710
SKP79
SKP78
Reserved
R/W
765
4321
0
SKP77
SKP76
SKP75
SKP74
SKP73
SKP72
SKP71
SKP70
R/W
765
4321
0
res
res
res
res
res
JMP10
JMP9
JPM8
Reserved
R/W
