background image
ADD8704
ELECTRICAL CHARACTERISTICS (CONTINUED)
Parameter
Symbol
Condition
Min
Typ
Max
Unit
DYNAMIC PERFORMANCE
Slew Rate
SR
RL = 2 kΩ, CL = 200 pF
4
6
V/µs
Gain Bandwidth Product
GBP
RL = 10 kΩ, CL = 40 pF
5.8
MHz
–3 dB Bandwidth
BW
RL = 10 kΩ, CL = 40 pF
6.8
MHz
Phase Margin
Øo
RL = 10 kΩ, CL = 40 pF
55
Degrees
Channel Separation
75
dB
NOISE PERFORMANCE
Voltage Noise Density (A, B, and C)
en
f = 1 kHz
26
nV/√Hz
en
f = 10 kHz
25
nV/√Hz
Voltage Noise Density (D)
en
f = 1 kHz
36
nV/√Hz
en
f = 10 kHz
35
nV/√Hz
Current Noise Density
in
f = 10 kHz
0.8
pA/√Hz
Rev. 0 | Page 4 of 16
