ADD8704

Rev. 0 | Page 5 of 16

ABSOLUTE MAXIMUM RATINGS

Table 3. ADD8704 Stress Ratings1

Parameter

Rating

18 V

Input Voltage

Differential Input Voltage

Storage Temperature Range

–65°C to +150°C

Operating Temperature Range

–40°C to +85°C

Junction Temperature Range

–65°C to +150°C

Lead Temperature Range

300°C

ESD Tolerance (HBM)

±1500 V

ESD Tolerance (MM)

175 V

Table 4. Package Characteristics

Package Type

Unit

14-Lead TSSOP (RU)

180

35

°C/W

16-Lead LFCSP (CP)

383

303

°C/W

permanent damage to the device. This is a stress rating only; functional

operation of the device at these or any other conditions above those

indicated in the operational sections of this specification is not implied.

Exposure to absolute maximum rating conditions for extended periods may

affect device reliability.

soldered onto a circuit board for surface-mount packages.

ESD CAUTION

ESD (electrostatic discharge) sensitive device. Electrostatic charges as high as 4000 V readily accumulate on the

human body and test equipment and can discharge without detection. Although this part features proprietary

ESD protection circuitry, permanent damage may occur on devices subjected to high energy electrostatic

discharges. Therefore, proper ESD precautions are recommended to avoid performance degradation or loss of

functionality.
